PLT-1215-F

Document

FEATURES

PLT-1215-F, a 15-inch high-power two-way full-range loudspeaker, is characterized by the brightness and dynamism of its tone. It is equipped with a 1 x 15-inch high-efficiency mid-woofer and a 1 x 1.4-inch 75mm titanium membrane high-frequency driver with a 90° x 40° rotatable horn for precise sound orientation. The cabinet construction is made of multi-layer composite plywood with an abrasion-resistant polyurea finish to ensure durability.

2400W watt Rated Power
138 dB max SPL
35Hz-20kHz frequency response
2 x 15"woofers + 1 x 2"HF transducer
Built with top-notch components
Energy-efficient power output

TECHNICAL SPECIFICATIONS

FREQUENCY RESPONSE

40Hz-18kHz (-3dB)

35Hz-20kHz (-10dB)

DRIVERS

2×15"(385mm)/4" voice coil LF

1×2"(50mm)/3" voice coil HF

RATED POWER

1200W RMS, 4800W peak

SENSITIVITY

101dB 1watt/1 meter

MAXIMUM SPL

132dB continuous, 138dB peak

IMPEDANCE

4 ohms nominal

DISPERSION(-6dB)

90°×50°

CROSSOVER FREQUENCIES

1.5kHz passive

INPUT CONNECTORS

2 xSpeakon NL4

DIMENSIONS

(W)500mm×(H)1130mm×(D)560mm

NET WEIGHT

64kg/pc

Accessories

Flying ring
